Brand
Guidelines
How Alert Enterprise looks and sounds: logo, colors, type, images and words, with live examples and downloads.
Identity
Our logo is a coral shield beside the Alert Enterprise name. Place it on white, black or purple.
Direction
Alert Enterprise is a security company that looks like modern software: frosted glass over soft color, large clear type, clean product screens. Locks, shields and badges are welcome. Old-fashioned styling is not.
Show security subjects with a modern software look. rule: modern-software
One language across our whole portfolio. Mobile credentials, visitor management, identity governance and physical access share the same colors, type, shapes, glass, motion and icons. Products differ by name and by the icons they use, never by their own palette or styling. rule: one-language
Logo
Three backgrounds our logo can sit on.
Place our logo on white, black, night (#0E0B2E) or brand purple (#5F51D5) only. rule: logo-grounds
Try a background
Pick a color to see if our logo can go on it.
Shield
Four parts. Only the left fold has a gradient.
- Fold. Coral fading into red.
- Face. Solid coral, #FF5233.
- Base. Solid coral, curving into the fold.
- Cut. Always white.
Clear space and smallest size
Leave empty space around our logo as wide as its shield. Drag to find the smallest allowed size.
Keep clear space equal to shield width on all four sides. Minimum logo width: 120 pixels on screen, 30mm in print. Shield alone: 16 pixels. rules: logo-clearspace, logo-minimum
Explaining, and showing
Two registers, and the wrong one in the wrong place is the usual mistake.
A drawing that explains goes in a brief, a doc or a ticket. Flat, on the page surface, grey and purple, readable when it is printed and when someone drops it into an email. Everything above is this kind.
A drawing that shows what we have built goes in a keynote, on the website or on a launch slide. Glass over the mesh, one idea per picture, no arrows to trace. It carries the brand rather than the detail, so it says less: a reader who needs the detail gets the first kind.
Neither borrows from the other. A flat drawing on the mesh is unreadable, and an architecture drawn in glass hides the thing it is trying to explain.
What not to do
Small spaces: browser tabs, app icons, avatars
The shield stands in for the full logo when there is no room for the name. Shown at the size each one is actually used.


Use the shield alone, never a shrunken full logo and never letters. On dark app surfaces use the white shield on purple; everywhere else use the coral shield. rule: small-space-mark
<link rel="icon" type="image/svg+xml" href="/ae-shield-coral.svg"> · <link rel="apple-touch-icon" href="/ae-shield-180.png"> · web app manifest: 192 and 512, plus the purple version as maskable.
Which file to use
These files stay sharp at any size.
| Version | Use on | File | ||
|---|---|---|---|---|
| Coral shield, ink name | White. Default choice. | ae-logo-full-coral-ink.svg | Download | |
| Coral shield, white name | Black, night and brand purple. | ae-logo-full-coral-white.svg | Download | |
| One color, ink | One-color print, fax, embossing, etching. | ae-logo-full-allblack.svg | Download | |
| One color, white | One-color white, on purple or on a darkened photo. | ae-logo-full-allwhite.svg | Download | |
| Shield, coral | App icons, website tab icons, profile pictures, slide corners. Show our full logo first. | ae-shield-coral.svg | Download | |
| Shield, one color | Ink or white outline, for one-color work. | ae-shield-allblack.svg | Download |
Naming
How to write our company and product names.
Company name
Always Alert Enterprise: two words, both capitalized. AE is fine internally and where space is tight, but not in customer writing on first mention.
| Write | Not |
|---|---|
| Alert Enterprise | AlertEnterprise · Alertenterprise · Alert enterprise · ALERT ENTERPRISE · Alert |
| Alert Enterprise's (possessive) | AE's, in customer writing |
The company is always "Alert Enterprise", two words. rule: company-name
How the names fit together
Four levels, one language.
- Alert EnterpriseThe company. Always appears first in any material.
- GuardianThe platform our products run on.
- ProductsPIAM, Visitor Management, Wallet Mobile Credentials, SOC Insights, AI Agent, Asset Governance.
- CapabilitiesEverything inside a product, described plainly: mustering, kiosks, building management, policy-based access control.
Only Alert Enterprise has a logo. Products are set in Aeonik beside the shield, never given their own mark, colors or typeface. rules: one-language, product-names
Products
Guardian is our platform. Products sit on it and use plain descriptive names. Write them exactly as shown.
| Write | What it is | Not |
|---|---|---|
| Guardian | Our platform. Everything runs on it. | Enterprise Guardian · AE Guardian · the Guardian platform |
| PIAM | Physical identity and access management: who may go where, and for how long. | Guardian PIAM in running text · PIAM platform |
| Visitor Management | Inviting, clearing and checking in visitors. | Visitor Identity Management · VIM · visitor mgmt |
| Healthcare VIM | Visitor management for hospitals, connected to patient records. | Patient Visitor Management · Hospital VIM |
| Wallet Mobile Credentials | Badges in Apple, Google and Samsung wallets. | Mobile Wallet Credentials · NFC Wallet Mobile Credentials · mobile wallet credentialing |
| SOC Insights | Security operations intelligence. | SOC Insights & Response · SOC Insights+ |
| AI Agent | The assistant that answers questions and acts inside Guardian. | Guardian AI Security Agent · AI agent for physical security |
| Asset Governance | Control of company assets alongside identities. | Asset Management · Asset Governance Platform |
| Employee Badge in Apple Wallet Corporate Badge in Google Wallet Company ID in Samsung Wallet | The wallet credential names set by Apple, Google and Samsung. | Apple Wallet badge · Google badge · Apple employee badge |
Everything below a product is a capability, described in plain words rather than named like a product: emergency mustering, building management, workspace intelligence, identity intelligence, policy-based access control, kiosks, the ServiceNow integration. rule: product-names
Partners and hardware
Alert Enterprise makes software. Badge readers, locks and cards are made by partners such as HID, Wavelynx and LEGIC. When hardware appears in writing, screens or images, name its maker, and spell partner names their way.
Never say or suggest that Alert Enterprise makes hardware. rule: software-company
Co-branding
Showing our logo next to a partner's logo.
Side by side
Our logo first, a thin line, then our partner's logo. Both should look equally tall.
"Built with Wavelynx readers"
"The AE HID Reader"
Apple Wallet and Google Wallet buttons
Use official buttons only, exactly as supplied.

- Google: black only, at least 48 pixels tall, with 8 pixels of clear space. As large as any other button beside it.
- Apple: clear space of one tenth its height. Keep it secondary to our own message, and show it next to a pass. In an iOS app, use the system button instead of this image.
- Both: never recolor, stretch, rotate, dim or animate. Use each market's language version; other languages are in the full kit.
Color
Purple is our main color. Coral is an accent, used sparingly. Text is near-black. Green, amber, red and blue mean status only, such as granted or denied.
Brand colors
Click a color to copy its code.
Purple
- Hex
- #5F51D5
- RGB
- 95 81 213
- CMYK
- 55 62 0 16
- Use
- main
Coral
- Hex
- #FF5233
- RGB
- 255 82 51
- CMYK
- 0 68 80 0
- Use
- accent
Gradient red
- Hex
- #F9423A
- RGB
- 249 66 58
- CMYK
- 0 73 77 2
- Use
- gradients only
Ink
- Hex
- #262626
- RGB
- 38 38 38
- CMYK
- 0 0 0 85
- Use
- text
Use gradient red (#F9423A) only inside gradients, never as a solid color. rule: f9423a-gradient-only
Lighter and darker shades
Click a shade to copy it.
Softer versions
When a brand color is too strong, use it at 80, 60, 40 or 20 percent. No other amounts.
Purple first, coral sparingly
One card, done right and wrong.
Requested by Priya Raman 2
Requested by Priya Raman
Use coral sparingly: our shield, one highlight, part of an icon, one chart line. Never use coral for errors. Errors are red (#E0425C). rules: coral-marks, coral-is-not-danger
Where each color goes
Switch between Light and Dark at top right to see these change.
| Used for | Color |
|---|
Is it readable?
Pick a text color and a background to check readability.
Guardian Mesh
Guardian Mesh, our partner channel, uses this system in black, white and gray. Color is kept for status.
Grays
Click a gray to copy its code.
The grays are --ae-gray-0 to --ae-gray-950. Status keeps --ae-green-*, --ae-amber-* and --ae-red-*.
Light and dark
The same components in the Guardian Mesh colors.
Guardian Mesh uses its own logo and these colors. Black takes the place of purple and coral, and white does in dark mode. Green, amber and red mean status, always with their word. Type, spacing, shapes, glass, motion, components and wording stay the same. rules: mesh-color-set, one-language, product-names
Turn it on with data-brand="mesh" on <html> or any container. It works with data-theme and with print. Icon files for Guardian Mesh: assets/icons/mesh/ on a light ground, assets/icons/mesh-dark/ on a dark one.
Gradients
Brand gradients are soft and cloud-like, with color glowing from more than one point. Never a straight fade from one color to another.
Gradients
Click one to try it below.
Try it
Drag either circle to move its color. Copy the code for use on a web page.
Soft, not straight
Typography
Our typeface is Aeonik: Bold for headlines, Regular for text, Light for very large type. Use DM Sans only if Aeonik cannot be used.
Get Aeonik
Use Aeonik for all Alert Enterprise materials: documents, presentations, email, websites, video and print. Install it, and embed it when saving presentations and documents.
Double-click each .otf and choose Install Font, or run: bash install/install-aeonik.sh
Use Aeonik for all company materials, and embed it when saving presentations and documents. rule: aeonik-everywhere
Aeonik
A clean, modern typeface that works for headlines and for long text.
ABCDEFGHIJKLMNOPQRSTUVWXYZ
0123456789 $%&(.,;:#!?)
Three weights
Type in any line to try it. Drag to resize.
| Weight | Number | Use |
|---|---|---|
| Light | 300 | Very large type only. Never for small text. |
| Regular | 400 | Body text and subheadings. |
| Bold | 700 | Headlines, buttons and emphasis. |
Only these three weights exist. Do not use Medium or Semibold.
Aeonik and its backup
DM Sans is a free font that looks close to Aeonik. Use it only when Aeonik cannot be used.
--ae-purple-500
Scale
Fourteen text sizes, from largest headline to smallest note. Click any line to type your own words.
Writing tips for type
- Sentence case for headings, buttons, labels and menus. Title case only for product names.
- Align body text to the left. Keep lines to about 45 to 75 characters.
- Large headlines are set slightly tighter. Only small labels above a heading are in capitals.
- Numbers in tables line up in straight columns.
- Badge numbers and codes use a fixed-width font. Sentences never do.
Space
Spacing comes in set sizes, from 4 pixels up to 128. Use these sizes, not values in between.
Scale
Too tight, too loose
Drag to change spacing inside this card.
Facilities · Building 4
Corners and shapes
Buttons have slightly rounded corners; cards, a little more. Our brand shape is the shield: one large rounded corner.
Rounded corners
Buttons and text boxes: 8 pixels. Cards: 16 pixels. Pop-up windows: 24 pixels. Fully round ends are for tags and switches, not buttons.
Shield shape
Three small corners and one large one. Drag to see how much that large corner matters.
Where it goes
Use shield shapes for color samples, photos and feature tiles. Never on buttons or text boxes. rule: shield-shape-not-controls
Layout
Pages use twelve equal columns. Turn on Grid at top right to see them.
Columns
A common layout: a narrow column for headings, a wide one for content.
Screen sizes and widths
Each bar marks a screen width where layouts adjust.
| What | Width |
|---|---|
| A column of text | About 68 characters |
| Pages and documents | 1120 pixels |
| Product screens and dashboards | 1440 pixels |
Shadows and glass
Shadows are soft and slightly purple. Most things have no shadow at all.
Shadow levels
| Level | For |
|---|---|
| 0 | Cards and tables. Usual choice. |
| 1 | Small raised details, such as a selected tab |
| 2 | Menus and product screenshots |
| 3 | Notifications and cards when you point at them |
| 4 | Pop-up windows |
| brand | Main button in a title area |
Glass
Frosted glass panels over photos and gradients. Switch the background to compare.
Use glass only over photos or gradients. On a plain background it just looks gray. Never stack glass on glass. rule: glass-on-image
Glass in use
A floating menu, a search panel, a card and buttons, all in glass. Move your pointer over it.
.ae-glass, .ae-glass--clear, .ae-glass-bar, .ae-btn--glass, .ae-cmdk
Motion
Movement should explain what changed. Things slow down as they arrive and speed up as they leave. A small bounce is saved for confirmations, such as access granted.
Ways of moving
Click one to see it move.
Side by side
Five ways of moving, over equal distance and time.
How long things take
Click to feel each one.
| What moves | How long | How |
|---|---|---|
| Hover, press, color change | fast · 140ms | standard |
| Toggle, check, select | base · 220ms | spring |
| Menu, tooltip, toast in | slow · 360ms | enter |
| Anything leaving | base · 220ms | exit |
| Pop-up windows and panels | slow · 360ms | enter |
| Animating our shield and icons | draw · 900ms | draw |
Reduced motion
Some people turn on "reduce motion" on their device. For them, movement becomes a quick fade and nothing repeats. Reduce motion, at top right, shows how that looks.
Respect reduce-motion settings. rule: reduced-motion
Animations
Animations for videos, presentations and product screens, each one playing on a light and a dark background.
One pass, along one axis, and nothing bounces back. Things arrive, settle and stay. rule: reduced-motion
Buttons and controls
Buttons, text boxes, switches and other pieces used in Alert Enterprise products. Try them. Turn on Developer details for code names.
Buttons
Buttons in each state: resting, pointed at, pressed, reached with the keyboard, loading and unavailable.
.ae-btn with --tonal, --outline, --text, --danger; sizes --sm, --lg; --icon. Busy is aria-busy="true".
Text boxes
Type an email address without an @ and click away to see an error.
.ae-field wraps a label, control, help and error. Set aria-invalid="true" and the error replaces the help.
One-time code
The code we email or text to confirm it is really them. One box for the whole code, so it can be pasted, filled in by the phone, and read out by a screen reader. Say where the code went and how long it works.
.ae-input--code on one input, never a box per digit. Always type="text", inputmode="numeric", autocomplete="one-time-code", maxlength and pattern="[0-9]{6}" for six digits, a visible label, and no placeholder. The help line says where the code went. Resend is a text button under the field; while it cools down it carries aria-disabled="true" and its own label counts down, outside any live region so it is not read out once a second.
Choices
Checkboxes, round options, switches, and tabs.
.ae-check, .ae-radio, .ae-switch style native inputs, .ae-segmented and .ae-tabs use aria-pressed or aria-selected.
Status labels
Colored labels showing granted, denied, pending and other states. Wording is fixed; see Terminology.
.ae-badge in seven tones, with --dot and --live. Status words are fixed: see Terminology.
Pop-ups and notifications
A confirmation window, a notification and a hint that appears when you point at a button.
.ae-dialog is a native <dialog>. .ae-toast appears bottom right. .ae-tip reads data-tip.
Agreeing to terms
When someone has to accept a text before going on: a confidentiality notice, terms of use. Show all of it, say exactly what ticking the box agrees to, and name the button for what happens next. The button waits until the box is ticked.
.ae-consent holds .ae-consent__title + .ae-consent__text + any field + .ae-consent__accept + .ae-consent__foot. The text region takes tabindex="0", role="region" and aria-labelledby pointing at the title. The button carries aria-disabled="true" until the box is ticked. For long text in a window, .ae-dialog--lg, with the button in .ae-dialog__foot. Record the text as shown, its version, the typed name and the time.
Show the whole text on the page; a link to it does not count. The box starts unticked and says what it agrees to. The button names the action, such as "Accept and view quote", and waits for the box. rule: consent
Waiting and loading
Match the wait to what is happening. Pick by how long it takes and whether we know the length.
.ae-spinner, .ae-skeleton, .ae-progress, .ae-ring, .ae-stepper, aria-busy="true"
| How long | Show | Why |
|---|---|---|
| Under a moment | Nothing | A flash of a spinner is worse than a short wait. |
| A second or two, loading content | Skeleton | Shows the shape of what is coming, so the page does not jump. |
| A second or two, after a click | Spinner in the button | Keeps the response where the person is looking. |
| Longer, length known | Progress bar | People wait longer when they can see the end. |
| Longer, length unknown | Spinner with a line of text | Say what is happening: "Checking with the reader". |
| Much longer | Let them leave | Tell them we will notify them when it is done. |
- Details
- Host
- Access
- Review
Never show more than one waiting indicator for the same wait. A skeleton, a spinner and a progress bar together read as three separate problems. rule: one-wait-indicator
Keep the layout still. A skeleton takes the space its content will take, so nothing jumps when it arrives.
Tables
Click a column heading to sort. Click a row to select it.
.ae-table. Click a header to sort, a row to select. Numeric columns take .num, codes take .mono.
| Name | Department | Badge | Status | Doors |
|---|
Prices and totals
A price list, a quote or an invoice. Amounts line up on the right so the digits stack, and the total sits at the foot in bold.
.ae-table--dense for tighter rows. Totals go in tfoot, and the last row takes .ae-table__grand-total. Amounts take .num; a line with no charge takes .num .nil. On paper the totals print once, at the end.
Write money the same way everywhere: $12,400.00, with the symbol touching the number and commas in the thousands. A discount or a credit takes a true minus sign, −$1,200.00, never brackets and never a hyphen. A line with no charge says Included or None rather than $0.00. rule: money-format
| Item | Quantity | Unit price | Per year |
|---|---|---|---|
| Mobile credentials, per badge | 1,200 | $18.00 | $21,600.00 |
| Visitor Management, per site | 5 | $4,800.00 | $24,000.00 |
| Onboarding and training | 1 | Included | Included |
| Subtotal | $45,600.00 | ||
| Three-year discount, 10% | −$4,560.00 | ||
| Total per year | $41,040.00 | ||
Documents and printing
A document someone reads and may print or save as a PDF: an agreement, a report, a quote. On screen, a page is a sheet of paper with the printer's margins, so the screen and the PDF match.
On paper it is always light. Buttons and menus drop out, a heading stays with what follows it, a table's header row repeats when it runs onto a new sheet, and the foot of the sheet says who it was prepared for and the page number.
.ae-doc holds one .ae-doc__page per sheet, and .ae-doc__stamp goes under the title on the first page. Letter size with a 0.6in margin. The footer is a page margin box: set --ae-print-foot on :root to a quoted string, and the page number prints beside it. .ae-print-hide and .ae-print-only choose what reaches paper. Under @media print, tokens.css takes the light roles whatever data-theme says.
Access control renewal
Navigation
Where you are, and how to get somewhere else. One job per navigation: destinations in the side rail, depth in the breadcrumb, views of one thing in tabs.
.ae-shell, .ae-nav, .ae-tabbar, .ae-crumbs, .ae-glass-bar, .ae-cmdk, .ae-panel. The destination you are on carries aria-current="page" in all of them, so no product invents a second way to say it.
Under the md breakpoint the side rail gives way to the tab bar carrying the same destinations. Hiding the rail on its own leaves a product a person cannot move around. rule: nav-phone
A shell opens with a skip link to the main region, before the logo. It is the first thing a keyboard reaches, and the commonest thing missing from a shell. rule: skip-link
Empty, failed, offline and unavailable
What a screen or region says when it holds no content. Waiting is a separate case: see the loading section.
Unavailable is for something that can no longer be opened: a link that expired or was withdrawn, or one locked after too many wrong codes. It is not a fault, so it stays calm, and it says what to do next.
.ae-empty, with --error, --offline and --unavailable. Same layout, different tone and different words. A failed region takes role="alert"; an empty list and an unavailable link do not. Unavailable paints its one-color icon in --ae-text-brand, never red and never coral.
Empty says what belongs here and how to add the first one. Failed says what failed and gives a way to try again. Offline says what is stale, when it was read, and what still works. Unavailable says whether the link expired, was withdrawn or was locked, and what the person can do. rule: screen-states
Filters, selection and paging
The bar above a table, what happens when rows are picked, and moving through a long list.
.ae-filters, .ae-bulk, .ae-pager. The page you are on carries aria-current="page", the same as every other navigation here.
Actions on a selection sit in one bar that names the count, because a button reading "Revoke" over a selection a person cannot see is how the wrong records go. rule: table-bulk
Filters that are on show as removable chips, with a way to clear them all and a count of what is left. rule: filters-visible
42 of 318
Product page
What a product screen is made of: content on a sheet, one page head, stats as tiles, cards with a head, and rows that open.
.ae-shell--sheet, .ae-page with .ae-page__head, .ae-stats and .ae-stat--tile (.ae-stat--needs in coral), .ae-card--dense, .ae-card--flush and .ae-card__head, and .ae-disclose on a details element.
Give a product page one head: the title at the product title size, one quiet line of meta, and the actions at the end. rule: product-page-head
Put the page's figures in one row of tiles above the content, and use coral only for a figure that is waiting on a person. rule: product-stats-row
Show a long list as rows that open. The row carries the name and its state; the detail stays closed until it is asked for. rule: disclose-detail
Facts, history and data
What a record holds, what happened to it, and the data behind it.
.ae-facts, .ae-timeline, .ae-code. A timeline entry takes data-state="needs" or "failed".
- Credential provider
- HID
- Access control
- LenelS2
- Licensed users
- 1,200
- Portal domain
- Not set
- Order signed
- Sent back for a portal domain
- Credential assets rejected
- First credential issued
{
"stage": "BUILD",
"status": "RUNNING"
}
Use a facts list for one record and a table for many. Show a missing value as "Not set", not as a blank. rule: facts-not-table
Upload
One file, by click or drop, checked when it is chosen.
.ae-upload, a label around a file input. data-state="over" and "done", and aria-invalid="true" with the reason in .ae-upload__error.
State a file's limits before it is chosen, and give the measured value when it fails. rule: upload-limits
Pass
A wallet credential, drawn. Logo top left, holder's name bottom left, artwork across.
.ae-pass with .ae-pass__art, .ae-pass__logo, .ae-pass__name. .ae-pass--sm for a small one.
Draw a Pass as an illustration, never as a provider's real artwork, and show no badge number on the front. rule: pass-illustration
Agent proposals
An agent proposes and a person decides. The parts run in the order the decision needs them: what changes, what it touches, where it came from, then the buttons.
.ae-proposal, .ae-source, .ae-stream, .ae-ai. The change is marked up as del and ins, which already mean removed and added, so it reads without colour.
Say what cannot be taken back while the person can still say no, and put it on the button: "Revoke 14 badges", not "Confirm". rule: agent-undo
What an agent states carries the record it read, beside the claim. A claim with no record behind it stays off the screen. rule: agent-source
Contractor, no lobby accessContractor, Lobby A, weekdays 07:00 to 19:00
1 person, 1 area. Expires 30 Sep 2026.
Requested in REQ-4182
System email from every product shares one header and footer. Seven kinds of message cover what a product sends. Open a sample in a new tab, on a phone and in dark mode.
The kit is email/: templates ae-action, ae-code, ae-notice, ae-alert, ae-decision, ae-summary, ae-report.
- An email client is not a browser, so none of the stylesheets apply. Send with a template from the kit before writing email markup.
- Type:
font-family: Aeonik, 'Helvetica Neue', Helvetica, Arial, sans-serif, with Aeonik loaded by@font-face. The stack takes over where a client ignores web fonts. Weights 400 and 700. - Inline CSS on the elements themselves, values written out from
tokens/dist/tokens.flat.json, becausevar(--ae-*)does not work in mail. Tables for layout. - Inline styles are the phone layout. The wide layout is one
@media (min-width: 621px)block. One column, up to 600px, centered. - Header in night
#0E0B2Ewith the dark mesh over it. One glass panel, on the header only. - Light body with a dark version in
@media (prefers-color-scheme: dark). Motion only inside@media (prefers-reduced-motion: no-preference). - One primary button in
#5F51D5, built as a table cell around a link, labelled with what happens: "View quote". Other links in#4A3EC1. - The lockup as a PNG with
alt="Alert Enterprise", never below 120px wide. On the night header:assets/logo/ae-logo-full-coral-white.pngatwidth="150". On white:assets/logo/ae-logo-full-coral-ink.pngatwidth="240". - A plain text part with the same words and the full link.
- No gradient carries meaning: many clients drop background images.
Product screens
Guardian screens built from the pieces above. Click rows, filters, buttons and the search box. Activity is simulated.
Icons
Two-color line icons: purple outlines, coral details. Original and new sets appear together for comparison. Each icon can draw itself on.
Drawing rules
Follow these when drawing a new icon.
Recipe and the icon list: assets/icons/icons.json. New icons: scripts/build-icons.py. Check: python3 scripts/check-icons.py.
icon-shield-lock
Click an icon above to see it larger.
Use icons in purple and coral. Single-color icons are only for small spaces such as menus and buttons. rule: icons-two-tone
Photography
People at work in the industries we sell into, lit naturally. Search it, or pick an industry.
Nothing matches that.
Picking one
- People doing their work, looking at the work rather than at a camera.
- Industry settings, healthcare, utilities, oil and gas, manufacturing, food and beverage, balanced with office life.
- Badges, lanyards, turnstiles and phones are good. Any reader or lock in shot should be plain, or made by a partner.
- Daylight, warm and saturated.
- No faces cut at the eyes, no posed handshakes.
- Put a photo behind glass or under a scrim before putting white text on it.
What not to do
Color and text on a photo
management
For developers
Everything here is in assets/photos/photos.json.
Every photo carries a focal point, two fractions of its width and height. Multiply by 100 and it is an object-position, which is what keeps a face out of the cut when the frame is square or tall.
<img src="/assets/photos/preview/substation-crew-walking.jpg"
alt="Two utility workers in hi-vis walking through a substation"
style="object-fit: cover; object-position: 31.7% 23.6%">
Three sizes of each photo: full at 2400px, preview at 1000px, thumb at 480px. Each entry also carries bottomLuma, how bright the lower third is, so you know whether white text needs a scrim. For the shield, add border-radius: var(--ae-shape-shield) or the .ae-shield-shape class, once on a page.
Charts
A chart answers one question. Purple carries the data, coral marks a point worth noticing, and green, amber and red mean status.
Color order
Four slots for identity, taken in order. Past four, group the rest as Other or split the chart.
Checked for red and green colorblindness, and for contrast on a card, in light and dark.
Take the slots in order and do not cycle them. Slot order does not depend on what the series is about. rule: chart-slots
Green, amber and red mean granted, expiring and denied. Never use them to tell one ordinary series from another. rule: chart-status-reserved
Magnitude and polarity
Two scales for values rather than identity.
How much: one hue getting stronger. Heat maps and density.
LeastMost
Which side of a baseline: two hues with a gray middle.
BelowOn targetAbove
Purple and coral stay out of both scales. Purple is the action color and coral marks one thing. rule: chart-ramps
Grid, axes and labels
Ink around the marks.
- Grid lines are faint and horizontal only. No box around the plot, no fill behind it.
- Labels are small and gray. Numbers line up in a column and use the fixed-width font.
- Draw a target or limit as a dashed line with its number at the end.
- Hover shows a crosshair and one tooltip. A chart with hover also offers a table.
- With no data, show a panel saying so, not empty axes.
Readable without color
Two or more series carry a legend. Four or fewer are also labelled at the end of the line or under the bar. rule: chart-not-color-alone
One value axis per chart. For two measures, use two charts or index both to a common base. rule: chart-one-axis
Which chart
Start from the question. Pick one to see it in our colors and type.
Getting it wrong, and right
Numbers and labels
- Group thousands with a comma. Write 12,482, never 12482 or 12.5k in a table.
- Round counts to whole numbers. Keep one decimal for rates, and only where it changes a decision.
- Name the unit once, in the title or the axis, and never on every bar.
- Say the period in words: last seven days, this month, since Monday.
- Give every chart a title that states the finding, not the field name. "Weekend traffic drops by three quarters" beats "Events by day".
- Put the number in a sentence wherever one number will do. A chart of one value is a waste of a chart.
Maps of regions
Who or what each area belongs to.
- A territory map is a chart. Each area takes the color of its owner, slots in order, four owners at most.
- Land that belongs to nobody stays in the empty color.
- Name every owner in the legend, and list the areas each one holds in a table. Color and shape alone do not tell a reader which states are meant.
.region on each area inside .ae-chart__plot, with .s1 to .s4 or .other
Charts in reports and slides
- One chart per point. If it needs two readings, it is two charts.
- Keep labels small and gray, grid lines faint, and leave out borders and background fills.
- Label lines directly at their ends instead of a legend when there are three or fewer.
- Charts inherit the page. On a dark slide the same chart keeps its colors and flips its labels.
Status
One word for the state of a person, credential, device or task. The same words in each product.
The words
Sixty states, four colors. The word is always shown.
Use these words as written. Do not invent alternatives such as Okay, Problem or Needs attention. rule: status-scale
Show the word, not the color alone. A colored dot fails for red and green colorblindness, and in print. rule: chart-not-color-alone
Severity
How much an event matters. A separate scale from status.
Four levels.
Writing a state
- Capitalized in a badge, lowercase in a sentence.
- Name the current state: Expired, not Expiry processed.
- Suspended is reversible. Revoked is not.
- Use Not known where there is no record. Do not leave the cell empty.
- Show the time the state changed.
Plans and maps
Floor plans and site maps, with the doors, routes and people drawn on them.
Parts of a plan
Four layers in one drawing: building, zones, doors, people.
Draw rooms and corridors faintly, and doors, routes and people in full. A person takes a chart slot for identity, and their state is written beside the plan. rule: plan-reading
Drawing a plan
- Label rooms, not walls.
- Draw a door as a block on its own wall.
- Planned routes are dashed. Walked routes are solid and draw on top.
- Keep one orientation for a plan, including in reports.
- Show the time of the last update.
- Draw a zone as a fill under the rooms, not an outline.
Diagrams
The drawings in a brief, a deck or a doc: what connects to what, what happens in order, and what something can be.
Which drawing
Pick by the question being asked.
- An integration map when the question is what connects to what. Systems on the outside, Guardian in the middle, arrows for the direction data moves.
- A sequence when the question is what happens in order, and who does each part. Time runs down the page.
- A lifecycle when the question is what something can be. The states from the Status section, and the moves between them.
- A floor plan when the question is where. That one has its own section.
- A chart when the question is how many. That one does too.
An integration map
Systems of record on one side, what we drive on the other.
In a diagram, color means something. Grey is every other system, purple is ours, and coral marks the one path being explained. A box is never colored to tell it apart from the box beside it; position and its label already do that. rule: diagram-color-meaning
A map a person builds
The integration map as buttons, for setting up a customer.
Show a system's state as a word beside its color: Needed, Chosen, Connecting, Connected, Failed. rule: systems-state-word
Use the maker's logo as supplied, in the logo box. Do not redraw or recolor it. .ae-systems__logo
A sequence
Who does what, in order. Time runs down.
A lifecycle
Every state a thing can be in, and the moves between them.
Drawing one
- One drawing answers one question. A drawing needing a key of more than four things is two drawings.
- A drawing reads one way, left to right or top to bottom. Hold the axis you pick.
- Name the boxes the way the products name them. A box labelled differently from the screen it stands for is a bug in the drawing.
- Label the arrows, not only the boxes. An unlabelled arrow makes the reader guess what moves.
- Aeonik throughout, at 14 pixels or larger. Nothing set in a lighter grey than the caption color.
- Depth carries meaning or it does not appear. A box that floats above another should be saying so. Clip art and SmartArt, never.
- Draw it as SVG on the tokens so it works in both themes and prints. A screenshot of a whiteboard is a note, not a drawing.
What not to do
- A palette per box, so the reader looks for a meaning in the colors that is not there.
- Arrows in both directions between the same two boxes. Draw the reply as a dashed line or leave it out.
- Vendor logos as boxes. Name the category, so the drawing survives the customer swapping a product.
- A drawing that names hardware we make. We make software; name the manufacturer when a reader or a lock appears.
- Text inside a shape it does not fit. Widen the box.
Slides
Presentation slides drawn from templates and the parts of this system. A slide holds its words, icons, pictures and builds; its template places them.
Canvas
- A slide is drawn on one canvas, 1920 by 1080, and scaled as one piece to the screen it is on. A slide looks the same in a browser, on a projector and in a PDF.
- Sizes on a slide are canvas pixels. Text takes a named role: a title is 64, an item heading 46, body text 34.
- Type is Aeonik, Bold for headings and Regular for copy.
- Light slides have a white ground and ink text. Section openers have a brand purple ground and white text, or the ink or white ground.
- A slide can carry a lead, one line under the title, and a callout, a statement in purple under its content.
React: SlideCanvas, SlideFrame. Slide data: lead, callout. Tokens: --ae-slide-width, --ae-slide-height, --ae-slide-lead-top, --ae-slide-body-top-lead, --ae-slide-role-*, --ae-slide-space-*, --ae-slide-icon-*, and the slide roles --ae-slide-ground, --ae-slide-text, --ae-slide-text-2, --ae-slide-accent, --ae-slide-rule, --ae-slide-mark-ground.
Templates
A template sets the ground, where each part goes and how its text is set. Steps share the width evenly; rows and lists keep one rhythm and sit closer when their text runs long.
| Template | Holds | Key |
|---|---|---|
| Section introduction | A section statement on brand purple, ink or white, with the section icon or a phone. A rule under the statement, a rule between the icon and the statement, or the statement and its line alone. The closing slide sets its statement larger, with a sign-off under it. | section-intro |
| Two-column content | Rows across both columns, ruled above, between or under, or a column of items each side with a highlighted step between. | two-column |
| Three-column content | Rows across the slide, ruled above, between or under, a list beside a logo wall, or a numbered step card per column. | three-column |
| Desktop and mobile | A desktop product beside a phone or kiosk, with text beside them. | desktop-and-mobile |
| Product with supporting evidence | One product screen with its statement and points. | product-evidence |
| Mobile product hero | A phone or product picture at either side, with headings and items. | mobile-hero |
| Multiple mobile screens | Several devices in a row with captions. | multiple-mobile |
| Sequential workflow | Stages of steps in order, joined by arrows. | sequential-workflow |
| Comparison matrix | Before and after, row by row. | comparison-matrix |
| Platform architecture | Layers, tiers and environments, boxes inside boundaries, joined by connectors. | architecture |
| Integration map | Systems around the platform in the middle, joined to it. | integration-map |
| Flow diagram | Steps in lanes or groups, with branches and decisions. | flow-diagram |
| Opening cover | The deck title and one line under it, on brand purple. With a customer, the Alert Enterprise logo, a rule and the customer's logo stand at the top. | opening-cover |
| Closing | Thank you, set as the cover sets its title, on brand purple or white, with the same customer lockup. | closing |
Each template has a content schema in SLIDE_TEMPLATE_REGISTRY; validateSlideDocument checks slide data against it. A server imports both from @alertenterprise/react/slides/schema. AGENTS.md section 3f.
- A presentation names the customer it was prepared for. The cover and the closing slide set the customer's logo beside the Alert Enterprise logo, a rule between; the other slides name the customer in their footer.
- A customer's logo that reads under 3 to 1 on its slide stands on a plate: white on purple, purple on white.
- With no logo, the customer's name is set in type.
React: SlideCustomerProvider, SlideCustomerLockup, ClosingSlide. Schema module: SLIDE_LOGO_GROUNDS, SLIDE_LOGO_MIN_CONTRAST, slideLogoPlate. Kit slides: KIT_SLIDES from @alertenterprise/react/slides/kit. Tokens: --ae-slide-lockup-*.
Presenting works as PowerPoint's slide show does, with the same keys, so presenters use the keys they know.
- Pen, highlighter and laser pointer draw over the slide, never on it. Ink stays with its slide for the show and is never printed.
- Ink colors are the brand's: red and yellow first, then teal, purple, black and white for a dark slide.
- The toolbar sits at the lower left and fades out when the mouse stops. Black and white screens, zoom and all slides are one key away.
- Presenter view shows the slide showing, the next slide or build, the notes at a size the presenter picks, the time presented and the clock, on the dark ground.
- Live subtitles sit at the foot of the slide, white on a dark band, two lines at most.
- The show ends on a black screen, as PowerPoint's does.
React: SlideShowStage, SlideShowFrame, SlideInk, SlideLaser, SlideZoomLens, SlideBlank, SlideShowEnd, SlideSubtitles, SlideShowToolbar, SlideSorter, SlideKeyHelp, SlidePresenterView, SlidePresenterPane, SlideTimer, SlideClock, SlideNotes, SlidePresenterNav, SlideEndShowButton. Geometry: slideCanvasPoint, slideStrokePath, slideStrokeHit, slideZoomClamp, slideZoomTransform. Tokens: --ae-slide-show-*.
Parts
- Text, rules, arrows and icons from the icon set.
- Icon with label, comparison row, figure, numbered step card, highlighted step and workflow step.
- Logo tile and logo wall, from each company's own logo file, each sized by its visible mark; a wall fits each group to its own grid.
- Product screen, phone, laptop, product window and kiosk. A screen can be a picture or a live product screen.
- A phone and watch with cards laid on them, and outlined panels in a phone's place.
- Grid item, quotation, logos in cells, a product screen in its frame and an enlarged part of it, bars and heat cells at slide size, and factor cells.
- Diagram box, boundary and connector. A diagram names what stands beside what and what joins what; the template sets the sizes and draws each line from the boxes it joins.
React: SlideText, SlideRule, SlideArrow, SlideIcon, SlideIconLabel, SlideRuledRow, SlideComparisonRow, SlideStat, SlideNumberedStep, SlideHighlightedStep, SlideFlowStep, SlideLogoTile, SlideLogoWall, SlideMediaView, SlideLaptop, SlideWindow, SlideItem, SlideQuote, SlideLogoRow, SlideLogoGrid, SlideScreenShot, SlideScreenDetail, SlideBars, SlideHeat, SlideFactorCell, SlideNode, SlideBoundary, SlideConnector, SlideDiagram. Diagram tokens: --ae-slide-diagram-*, --ae-slide-node-*, --ae-slide-connector.
Draw icons, logos and the lockup from the supplied files. On purple, an icon takes the one-color form in white. rules: logo-no-edit
Builds
What appears on each click.
- A part can wait for a presenter click. Parts on one click start together or one after another.
- Presented live, a slide plays: the title rises in, a line at a time, the lead after it, and each part arrives in reading order the way its kind moves. Text rises, lines draw, figures count up, logos arrive as a wave, a device's screen comes on, a diagram plays along its flow, a map lights its regions in turn.
- Each click plays the parts it brings in the same way. One slide crosses over the next; where the ground changes, the new ground opens out from the lockup or the title.
- The motion is paced for a room and plays whatever the viewer's device setting for motion.
- A PDF or a thumbnail shows each part in its last state, with no motion.
Slide props: step, mode="live" or "final", motion="stage" (default) or "plain". A build names the content it brings in by path. Tokens: --ae-slide-stage-*, --ae-slide-fade-*, --ae-slide-transition, --ae-slide-spin-*.
Footer
- Our logo goes at the lower left of each slide: ink name on white, white name on purple.
- Confidential and Copyright 2026 go at the lower right, in small gray type.
SlideFooter. Tokens: --ae-slide-logo-*, --ae-slide-legal-*, --ae-slide-role-legal.
On a phone
Sizes, sheets and navigation for phones and tablets. The sizes here are minimums.
Sheets and navigation
A sheet opens from the bottom edge. The bar stays on screen.
Granted
Priya Raman
Contractor, Brightline Electrical
North lobby, 09:42
Areas allowed
Touch targets are at least 44 by 44 pixels, with 8 pixels between them. Put the main action at the bottom of the screen. rule: touch-target
One sheet at a time, and no sheet on a sheet. A sheet closes by dragging down and by a close control. rule: sheet-behaviour
Layout on a phone
- Keep content clear of the safe areas at the top and bottom.
- Main action is full width.
- Body text is 16px or larger.
- One decision per screen.
- If a request fails, keep the last result on screen and name the failure.
- Nothing important behind a hover.
Voice
Plain, specific and calm. Our readers are busy security and facilities teams. Say what happened, or what a button does, in as few words as possible.
Principles
- State the fact. Name who, which door, what time. "Lobby A turnstile 2 is offline", not "An issue was detected".
- Label, don't explain. A setting says what it does. Why it exists belongs in documentation.
- No technical jargon on screen. Customers should not see engineering words such as endpoint, cache or webhook.
- No slogans in products. Headings describe; they do not sell.
- Name the manufacturer when hardware is involved. Alert Enterprise is a software company.
- Use the same status words. See Terminology below.
Before and after
Check your writing
Paste some text to flag words and phrases to avoid. It catches common problems; still read it yourself.
Style details
- Capitalize only the first word of headings and buttons. Product names keep their capitals.
- No em dashes or en dashes. Use a comma, a colon, parentheses or a second sentence.
- Use numerals (3, not three) in products. Use 24-hour time on screens (09:42) and 12-hour time in email and marketing.
- Dates: 22 Sep 2026 on screens, September 22, 2026 in writing, 2026-09-22 in file names.
- Buttons are verbs naming a result: "Revoke badge", not "OK" or "Submit".
- Errors say what happened and what to do next, in that order, without apology.
- No emoji in product, documents or email.
Terminology
Use one word for one thing. Words to avoid are marked in red.
- Identity
- A person known to our software: employee, contractor, visitor or vendor. Say "user" only for someone who signs in.
- Credential
- Anything that proves identity at a reader: a plastic card, a mobile credential, a PIN. General term.
- Badge
- A credential issued to a person, physical or in a wallet. "Employee Badge in Apple Wallet" is the product name. Avoid "pass" for employee badges.
- Site
- One physical location with its own address. A site holds areas and doors.
- Area
- A controlled space inside a site: a floor, a wing, a lab.
- Door
- One controlled opening, with a reader on one or both sides. Access levels are built from doors.
- Access level
- A named set of doors and schedules granted to an identity.
- Access request
- A request for an access level, with a requester, an approver and a decision.
- Visitor
- A person on site for a limited time, invited by a host. Visitors get a visitor pass, not a badge.
- Host
- Employee responsible for a visitor.
- Reader
- Device at a door that reads credentials. Made by partners such as HID, Wavelynx and LEGIC. Never imply AE makes readers.
- PACS
- Physical access control system: software and hardware that run doors. Spell it out on first use.
- Issue
- Give someone a badge or credential. Prefer "Issue badge" to "Provision".
- Revoke
- End a credential permanently. Distinct from suspend, which is reversible.
- Event
- A record of something that happened: access granted, access denied, a door forced open.
- Status words
- Granted, Denied, Pending, Expiring, Expired, Active, Inactive, Suspended, Revoked, Online, Offline. Capitalized as badges, lowercase in sentences.
- Admin page
- AE Verify settings and management screen. Avoid "console".
- USB reader
- Small desktop badge reader made by rf IDEAS. Avoid "dongle".
Accessibility
Our products and materials should be easy to read and use, including people with low vision and people who use a keyboard instead of a mouse. We follow the WCAG 2.2 AA accessibility standard.
Readable color pairs
Text and background pairs used in our products, checked for readability in light and dark.
| Scheme | Pair | Use | Ratio | Needs | Result |
|---|
Requirements
- Text stands out clearly from its background. Large text can be a little lighter.
- Anything clickable shows a purple outline when reached by keyboard.
- Buttons are big enough to tap easily.
- Never rely on color alone. Status labels always include a word.
- State lives in native attributes and ARIA (
disabled,aria-pressed,aria-selected,aria-invalid,aria-busy). - Movement can be turned down, and nothing flashes.
Downloads
Seven downloads: logos, Aeonik, icons, photography, gradients, wallet buttons and code.
Partner logos Transparent partner and technology artwork, with versions and usage guidance.
Use these files as they are. Never redraw, retype, recolor or restretch anything in them. rule: logo-no-edit
Single files are listed inside each download.
Using AI tools
AI assistants such as Claude or ChatGPT can follow these guidelines and produce work that already looks like Alert Enterprise.
Three ways to use them
Give your assistant the address of this page and ask for what you need. It reads the rules itself.
For assistants that cannot open links. One copy, then ask for a document, slide or page.
Colors, spacing, rules and assets are published in formats software can read.
Ask for what you want
Examples that work.
Click any example to copy it.
What an assistant knows
Once it has these guidelines, it will follow them without being told each time.
- Our colors, type, spacing, shapes, shadows and gradients, with the exact values.
- The rules, including which ones are firm and which are preferences.
- Which color pairs are readable, already measured.
- Where to find our logo, icons, fonts and photographs, and which file to use.
- How we write, and the words we avoid.
Updates
These guidelines are updated over time. Changes are listed below with a date.
Who to ask
- Matt Bennett owns these guidelines. Send questions and suggestions to him.
- Values change in
tokens/src/tokens.mjs, thennode tokens/build.mjsandnode scripts/build-agents.mjs. A change that fails a contrast check does not ship. Versions: a renamed or removed value is a major version, an addition is a minor, a small adjustment is a patch.
Open items
- ProductsAdd a complete list of product names.
- PhotographyConfirm web and partner rights for our photos.
- HostingDecide where these guidelines are published and who can see them.
What changed
- 1.51.016 Nov 2026. A prompt gallery with no links to AI tools shows Copy as a button of its own.
- 1.50.015 Nov 2026. Slides presented live play: titles rise in a line at a time, parts arrive in reading order the way each kind moves, figures count up, diagrams play along their flow, devices switch on, maps light their regions, and one slide crosses over the next. PDFs and thumbnails stay still.
- 1.49.013 Nov 2026. The slide kit carries what a presenter uses over the slides: pen, highlighter, eraser and laser pointer, black and white screens, zoom, all slides, keyboard shortcuts, the toolbar at the lower left, the end of the show and presenter view, drawn as PowerPoint draws them.
- 1.48.213 Nov 2026. A screen that reads the display's safe areas keeps one hidden measuring element on the page, and removes it when the last such screen closes.
- 1.48.113 Nov 2026. A validity field or date range filter in the reader's own time zone leaves out its time zone note when the product writes local time without a zone.
- 1.48.013 Nov 2026. A neutral tag has a hairline edge, so it reads as a tag on the light page, a card and a grid row, where its fill matched the ground.
- 1.47.013 Nov 2026. Slides name the customer a presentation is prepared for: the cover and a new closing slide set the customer's logo beside the Alert Enterprise logo, on a plate where it would not read, and the other slides name the customer in their footer.
- 1.46.013 Nov 2026. A prompt gallery can show what each request draws on, lighting up in turn, and the result drawing itself under it, and can play through its requests by itself, with a progress line on the current one; a click on a request jumps there and the gallery carries on.
- 1.45.013 Nov 2026. A product frame can leave out header Search, navigation search and Notifications when the product has no use for them. The header keeps its other controls and the account menu at the end, on every display. By default the frame keeps them.
- 1.44.013 Nov 2026. A scene player can keep its scene tabs as chapters and drop Pause: a tab plays its scene from the start and the player carries on. A setup guide can play its steps by itself, with a progress line under the step playing; a click on a step jumps there and the guide carries on.
- 1.43.013 Nov 2026. A product can show each reader dates and times in their own local time with the zone abbreviation left off, set once for the product. The Not authorized screen can show its title and actions alone.
- 1.42.013 Nov 2026. A step list shows the steps of a deployment or setup, each with who runs it, its status, one line of detail and one action, under a heading per environment, and shows go-live checks in the same form, unnumbered. Steps enter in sequence, and a step that completes turns to a check.
- 1.41.013 Nov 2026. The second kind of pin is coral with ink numbers, so it stands apart from the purple default pin in light and dark. It replaces the purple pin added in 1.40.0, which matched the default.
- 1.40.013 Nov 2026. A pin comes in brand purple, for a second kind of point on the same surface, such as distributors beside integrators on a map.
- 1.39.013 Nov 2026. A scene player plays itself with a progress line and no controls, moves the content in slowly toward the part that changes while the window holds still, fits a phone screen, counts figures up, and grows bars, columns and heat map cells as each scene runs. Narrow answer cards keep their titles whole.
- 1.38.1313 Nov 2026. Slides print as they show: dark and brand slides keep their colors, each slide prints as one piece, every fit settles when fonts arrive late, and device pictures load from the host's folder.
- 1.38.1213 Nov 2026. Slide logo measurements in the token notes and the changelog describe each logo by its size. A check for customer names runs before each deploy of this site. Customer and prospect logos moved to an internal library the site does not publish, and the name check reads that library.
- 1.38.1113 Nov 2026. Diagram connector labels stay clear of every line and frame, arrowheads stop short of text, logos in diagrams stand near their own size, and groups, bands and written title lines lay out as v2.1 sets them.
- 1.38.1013 Nov 2026. Slides outside diagrams sit closer to v2.1: devices in a row stand on one line, a kiosk beside a desktop starts level with its picture, paired screens run larger, the shield title and its lead, the contact slide and a row of product names stand where v2.1 sets them, a large logo group gets the room its logos need, and rows, steps and section openers keep v2.1's spacing.
- 1.38.913 Nov 2026. Diagram slides set node text at v2.1's sizes, step down only as far as they must to fit, set sparse diagrams a size up, keep every word inside its box, and draw each logo of a category in its own tile.
- 1.38.813 Nov 2026. Slide text stays inside the body: after layout the slide tightens its spacing, then steps its type down by roles, when content runs past the body. A line break inside a sentence holds only while each line fits. Grids and columns set their titles and text closer to the measured sizes. A section name on one line is set larger, a callout beside media stands under its text, and single logos fill their cells.
- 1.38.713 Nov 2026. Logos on slides follow one sizing rule: a row of logo groups shares one size, and each logo stands at most a quarter larger than its group's typical mark. Systems shown by name sit among the logos. In the Dark theme, accent text clears 4.5:1 and dark logos stand on a light plate.
- 1.38.513 Nov 2026. Mobile slides take their type from how much the content holds: a lone statement and a heading with its text set large, a crowded column a step down. Phones are labelled bold from their left edge, devices of one kind in a row stand one height, steps share the width by their pictures and a tall hero runs to the foot of the body.
- 1.38.413 Nov 2026. Diagram slides: connectors go round labels, text and boxes they do not join, and white space stays outside the boxes.
- 1.38.313 Nov 2026. Diagram slides place their items from the layout: row labels in a side column beside their rows, a filled band with its title beside its text, the platform at the end of a row raised above its peers, a node across rows hanging from its first, a sequence of steps on the node gap. Stage names and rules under a row.
- 1.38.112 Nov 2026. Live screens on slides: the phone draws its status bar and lays the screen out under the island, its glass clipped to the shell's rounded corners, and a screen for another device is drawn in that device, inside its box.
- 1.38.012 Nov 2026. Slide template variants (split, lists, quotes, logo table, product items, phones side by side, lock screen, devices with an aside, timeline, numbered columns, cards, lanes, comparison detail, labels and lists), Hub orbit, and four templates: opening cover, map with regions, phone fan and Guardian MCP.
- 1.37.012 Nov 2026. Diagram slides: platform architecture, integration map and flow diagram templates, with diagram boxes, boundaries and connectors drawn from the boxes they join; a lead beside the title or with the title in a side column.
- 1.36.012 Nov 2026. Slides: item grids, stat grids, a chart beside its text, product screens with an enlarged detail and numbered steps, and a factor grid on a dark panel.
- 1.35.012 Nov 2026. Slides: a live product screen in a slide picture, in the phone or kiosk drawn around it, as a task pane docked in a window, or in the displays of a device photograph.
- 1.34.012 Nov 2026. Slides: a lead under the title and a callout under the content; section openers on the ink and white grounds, with a phone, with a rule beside the statement, with the statement alone, and the closing slide; rows ruled above, between or under; layered devices and panels.
- 1.33.012 Nov 2026. Visitor Pass in the wallet badge panel, with the visit window and its facts; app frame for a visitor's own phone; Cancelled visitor card.
- 1.32.112 Nov 2026. Slide schema and validator in their own entry for servers; a build on the section opener's rule validates.
- 1.32.012 Nov 2026. Slide kit for presentations: a 1920 by 1080 canvas, nine templates, slide parts, builds and logo tiles sized by their visible mark; Guardian persona icons.
- 1.31.012 Nov 2026. Partner logo library with 157 marks and a searchable gallery; database, cache and load balancer icons; Guardian presentation screens.
- 1.30.112 Nov 2026. Scene player index: each tab as wide as its name, and a long name wraps instead of being cut short.
- 1.30.011 Nov 2026. Launch page parts: dark opening band, scene player for product demos, AI tool marks joined to the shield, approval request with its fields, request gallery with one featured, steps beside one screen.
- 1.29.210 Nov 2026. Pointer and pointer-click icons, and the drawn screens point with the pointer icon.
- 1.29.110 Nov 2026. A step guide keeps each step's detail under its words, and a menu path wraps between names inside a sentence.
- 1.29.010 Nov 2026. Request cards with fill-ins typed in place, a second row under the site head, the route a request takes, large link tiles, and drawn setup screens of other apps beside numbered steps.
- 1.28.09 Nov 2026. Image picker on a dark ground, for light artwork such as the pass designer's sample overlays.
- 1.27.09 Nov 2026. Sample artwork for the pass designer, and a wallet badge panel on an admin record with no Add to Wallet row.
- 1.26.031 Oct 2026. Copy button, numbered steps, request cards, site head and foot, and the sign-in step where an AI tool asks to connect to Guardian.
- 1.25.027 Oct 2026. Fifty more icons, from send and save to turnstile and elevator, in the Guardian and Mesh sets.
- 1.24.026 Oct 2026. The icon rules as a file of their own, for products that load icons without the component library.
- 1.23.026 Oct 2026. One copier for the repositories that keep a copy of the system.
- 1.22.026 Oct 2026. A second color set for Guardian Mesh: black, white and gray, with color kept for status.
- 1.21.023 Oct 2026. A row that opens keeps its whole title on a phone or in a narrow column, with its badges under it.
- 1.20.020 Oct 2026. A product whose customers have several sites narrows every screen to one site, or shows all of them, from its top bar.
- 1.19.020 Oct 2026. The pass designer as the Guardian Mesh builder runs it: steps in a rail, provider marks and their variants, text logos, the pass in its devices, gradient swatches, a layer list, option cards, slider resets and a version browser.
- 1.18.019 Oct 2026. A customer's mobile credential as Apple Wallet and Google Wallet show it, its back, and the files sent to the credential provider, all from one design.
- 1.17.019 Oct 2026. A product whose data belongs to one customer at a time names the open one in its top bar and switches from every screen.
- 1.16.119 Oct 2026. A page built on the system runs to the window's edges, with no white border from the browser around it.
- 1.16.019 Oct 2026. Status words for integrations: Not connected, Verifying, Connected and Syncing, for a directory, access control system or credential provider.
- 1.15.019 Oct 2026. A frame that shows an email as it reads in an inbox, at desktop or phone width, light or dark, and email previews drawn the way Postmark sends them.
- 1.14.019 Oct 2026. Large picture cards for a landing page that sends people on to sites or products: a picture of what opens, its name and one line, in light and dark.
- 1.13.018 Oct 2026. More for Guardian screens: font, color and show or hide rules on badge fields, a kiosk background shown whole, every response a rule can give, a comparison that shows it is loading, saved filters that survive a change of words, actions on a card, and sections of uneven height in balanced columns.
- 1.12.018 Oct 2026. More parts for Guardian screens: rows a person drags into order, a rich text cell in a list, a third line on a card, two versions compared side by side, bars and columns grouped for comparison, badge templates and a badge designer, a Data Matrix code, pickers for images and icons, and a kiosk shown inside a page.
- 1.11.018 Oct 2026. Product frames on a book-style foldable such as iPhone Duo: closed, the controls and tab bar stand in the column at the side; open, two panes split at the hinge, the screen on the right and new context on the left; upright, two panes one above the other. Opening and closing animate. Safe areas cleared on every phone.
- 1.10.016 Oct 2026. A scannable barcode for the back of a badge and for printed slips, in the four formats Guardian prints: Code 128, Code 39, Code 93 and Codabar. The value can be written under the bars, and a value a format cannot carry is named on screen instead of printing wrong bars.
- 1.9.116 Oct 2026. Fixes for Guardian screens: the back of a badge always fits the card, with its code smaller when the words need the room; the line under a printed QR code reads on a dark screen; a rule test with no sample people says how to add one, and starts closed on a phone; rules taken from the library no longer count as errors; a group on a map adds up its places' counts; an empty picture cell in a list stays empty; a row's actions in a tree no longer cut its name short; a schedule names its time zone so it matches its next runs; a placeholder in a tight list row stays on one line.
- 1.9.015 Oct 2026. More parts for Guardian screens: a map of places with groups, a card for the selected place and a way through to its record; a field for when a job runs, with its next runs in words; a list a person puts in order by dragging or by keyboard; conditions joined by AND or OR on each row, with Guardian's own operators; rule responses and rules picked from a library; more stage settings and decisions on a named rule in the workflow designer; a built form that can be filled and submitted; chips in a multi-select; images in a data grid; a code editor with Light and Dark and text inserted at the cursor; a selected row in a card list; actions on a timeline entry; a status control for a record header.
- 1.8.015 Oct 2026. Parts for Guardian screens: a scannable QR code for badges, kiosk visits and role prints; totals at the foot of a list and under each group; rows a person adds and removes in place; actions on each row of a tree; a tinted badge background; a status control that shows the product's own status words; a count shown in red when it reports errors. Icons for search, favorites, bookmarks and a smartwatch. One more status word, Not started. Turning off row selection no longer leaves a selection behind.
- 1.7.015 Oct 2026. Atlas is easier to notice in his corner without getting in the way. When something new arrives he hops twice and his tile lifts off the page with him. Between arrivals he breathes and, now and then, makes one small gesture, less often the longer a visit runs and never while you are working near him. He waves toward a line he offers, and brightens when you point at him.
- 1.6.015 Oct 2026. Dashboard lists such as Waiting on You and Activity now show a new item arriving the way other lists do, with the same brief mark. Long lists of thousands of records do too, without slowing down, and keep what is on screen in place while records arrive above it. When Atlas notices something new, he turns toward it and gives a small hop of his own.
- 1.5.015 Oct 2026. A chart that opens the records behind a bar, column, point or row now shows it: the pointer changes, the mark highlights, and View with an arrow appears beside it. Atlas can notice something that arrived for the person without saying a word. On a phone, the line he offers no longer covers what is on the screen.
- 1.4.015 Oct 2026. A record that comes in while its list is open slides in at its place and carries a brief mark, and the bell rings once for a new notification. A product can sit inside a frame of its own, such as two products side by side, with its windows, menus and messages staying inside it.
- 1.3.014 Oct 2026. Location and access lists in the request picker arrive and change the way every other list does. A menu shows its wait on its own button. A request's type or code travels into the record it opens, and a person named in a row opens their own record. A request can be rejected from a menu, with its reason, without leaving the list.
- 1.2.014 Oct 2026. Motion and loading. Every part a screen waits on draws a skeleton shaped like its content and hands over to it without a jump. Rows cascade in, leave and settle. A person opened from a list keeps their photo and name on the way to their record. Steps slide in the direction of travel, actions show their wait and confirm on what changed, counts tick, and a badge handed to its person has its own moment.
- 1.1.114 Oct 2026. A column chart of counts labels its axis in whole numbers. It was showing steps such as 0.2.
- 1.1.014 Oct 2026. Parts for Guardian screens: a toast region that places and times toasts, a list with one open item beside a reading pane, a badge card front and back, and a stage tag. Ten more status words, fifty-five in all. The reject dialog takes the product's own words, charts can leave out the total, and grid group headers carry actions.
- 1.0.314 Oct 2026. On a touch screen a check box, radio or switch keeps its size and gets a 44px target around it. The control itself was being stretched to 44px.
- 1.0.213 Oct 2026. The circle skeleton is round. A later rule was squaring its corners.
- 1.0.113 Oct 2026. The assistant question field stops at six lines and scrolls. Its height limit was not applied.
- 1.0.013 Oct 2026. First full release for Guardian. 80 of 81 Guardian interface elements have a part, a story and a rule. Map is not built.
- 0.17.013 Oct 2026. Atlas is the AI persona of the product, with a third stylesheet, atlas.css. Notifications: redrawn bell, panel title, severity on security alerts. Thicker horizontal bars. Workflow stage cards show three tags and "+N". Saved views carry a scope. Form builder: Formatted Text field name, rule captions removed. Sample lists open on demo personas. Product copy shortened.
- 0.16.113 Oct 2026. Kiosk ground is flat on every screen, site photograph behind Welcome only. Kiosk options take an icon color.
- 0.16.013 Oct 2026. Status words: twenty more, forty-five in all. Saved views, horizontal stacked bars, header actions and notifications, dashboard card content, windows that move and resize, sign-in run by the product, Security Policy, kiosk flow from configuration, wellness check, camera detector, AI chat voice, rating and projects, rich text table and color, code completion, rule code view, workflow stage settings, Grid and Html Element form fields. 17 more icons.
- 0.15.012 Oct 2026. Toolbar and menus, screen templates, sign-in and kiosk screens, location and access picker, rule, workflow and form designers, rich text, code and signature fields, import, organization chart, AI chat, wallet badge panel and agreement. 26 more icons.
- 0.14.012 Oct 2026. Email kit: one layout and seven templates for system email, with a night header, a glass panel, a dark version and Aeonik where the mail client loads it. The white lockup as a PNG for email.
- 0.13.012 Oct 2026. Data grid, date and time fields, dropdown and tag field, number, unit and password fields, person image, images and photo capture, identity and status, and attachments, comments and history. Nine more status words. Public Storybook.
- 0.12.09 Oct 2026. Data visualization set: thirteen more animated components, from segmented bar and ring to heat map, state timeline, status grid, flow, treemap, scatter, sparkline and relationship graph.
- 0.11.09 Oct 2026. Data visualization: animated Metric, Trend and Ranked components with entrance animation, value interpolation and hover response.
- 0.10.29 Oct 2026. More repairs: a stronger badge for Critical, one focus color, type sizes back on the scale, a plain search icon.
- 0.10.19 Oct 2026. Repairs: read-only fields, an error on a select, checkbox, radio and switch, and a disabled look for chips, tabs and segmented controls.
- 0.10.08 Oct 2026. Maps of regions: an area of a map filled by its owner, for territory maps.
- 0.9.06 Oct 2026. Product page parts: content on a sheet, a page head, stat tiles, a card head and rows that open.
- 0.8.26 Oct 2026. The systems map needs 960 pixels for three columns.
- 0.8.16 Oct 2026. The systems map stacks by its own width.
- 0.8.06 Oct 2026. Five parts for a record and its setup: Pass, upload, facts, timeline and code.
- 0.7.06 Oct 2026. A systems map: the integration map as buttons, for setting up a customer, with one link per system and a state on each.
- 0.6.025 Sep 2026. The lockup as a PNG for email, since Gmail and Outlook do not show SVG: 480px wide on white, rendered from the supplied file, not redrawn.
- 0.5.025 Sep 2026. Documents that print: a page on screen matches its PDF, paper is always light, and the sheets carry a footer and page numbers. Prices and totals, with one way to write money. A one-time code field, a way to agree to a text before going on, a wider window for long content, and a screen for a link that can no longer be opened. Guidance for email.
- 0.4.024 Sep 2026. Interface icons: 24 controls (close, check, chevrons, arrows, play, pause, refresh, upload, copy, trash, filter, key, battery, tablet, timer, flag and more), so a product screen never reaches for another library. 107 icons in total, with 132 intent aliases.
- 0.3.024 Sep 2026. Charts get their own colors: four identity slots checked for colorblindness and contrast, a scale for magnitude, a scale for polarity, and named colors for grid, axis, labels and the empty state. New sections for status words, floor plans and maps, and building for a phone. Plum and teal added as chart colors.
- 0.2.022 Sep 2026. New modern look: frosted glass, soft gradients, larger headlines and product screens in app windows. Plain-language rewrite.
- 0.1.122 Sep 2026. Company name set as two words. Aeonik downloads and installers added.
- 0.1.022 Sep 2026. First version.
